双引擎半排水体硬顶休闲汽艇(封闭式驾驶舱10人2舱传统型巡航艇)
产品图片
重要参数
    发动机类型 舷内
    引擎数量 双引擎
    船体类型 半排水体
    甲板布局 硬顶, 封闭式驾驶舱
    人数 最多容纳 10 人
    船舱数量 2舱
    风格 传统型
    甲板布置 日光浴
    其他特征 定制
    长度 11.48 m (37'07")

产品简介

类型:公爵 35

设计师:Andrew Wolstenholme 拥

有宽敞的内部和外部驾驶舱,为长达十天的客人提供充足的空间或豪华的周末泊位两人,我们创造了公爵 35 专门用于巡航和放松的风格。 更重要的是,我们可以定制它,包括任意数量的额外选项,无论您是想要选择单舱或双舱布局。 凭借双人舱布局,Duchy 35 是一款舒适的家庭巡洋舰。 凭借单舱布局,她是一个豪华的日间船最多可容纳十人和一对夫妇的周末巡洋舰。 您可以下载以下所有详细信息。

主要尺寸

有效空气:11.48 米(38 英尺)

LWL:10.08 米(33 英尺)

横梁:3.77 米(12 英尺 6 英尺)

冲水:0.84 米(2 英尺 9 英尺)

空气冲水

:排量:8.75 吨(约)

燃料容量:520 升(114 英尺)

水容量

:2 x 纳尼 T4.270标准规格包括

带洗脸盆的封闭式头隔间,电动马桶和淋浴间,带站立净空

冷热自来水到厨房和头部

低维护 GRP 船体和甲板

宽敞的轿车和驾驶舱与防水内饰

柚木甲板, 柚木沐浴平台和柚木驾驶舱底

电动风车, 20 公斤镀锌锚和 100 英尺的链条

一个手动和两个自动电动舱底泵

触摸屏 Raymarine 显示器与速度, 深度, GPS 图表绘图仪和控制所有

厨房包括双燃烧器炊具冰箱和不锈钢水

槽通过门到带游泳梯的沐浴平台

所有不锈钢配件,包括旗杆,鞋钉,护栏杆,挡泥板眼睛,导线,安全导轨,扶手,弓配件双滚筒,双角

英文介绍

Type: Duchy 35

Designer: Andrew Wolstenholme

With spacious interior and exterior cockpits that provide ample space for up to ten day guests or a luxurious weekend berth for two, we have created the Duchy 35 specifically for cruising and relaxing in style. What’s more, we can customise it to include any number of optional extras, whether you wish to select a single or twin cabin layout. With the twin cabin layout, the Duchy 35 is a comfortable family cruiser. With a single cabin layout, she is a luxury day boat for up to ten people and a weekend cruiser for a couple. You can download all the details below.

PRINCIPAL DIMENSIONS

LOA: 11.48m (38ft)

LWL: 10.08m (33ft)

Beam: 3.77m (12ft 6in)

Draught: 0.84m (2ft 9in)

Air draught:

Displacement: 8.75 tonnes (approx)

Fuel capacity: 520 litres (114gal)

Water capacity:

Engine: 2 x Nanni T4.270


STANDARD SPECIFICATION INCLUDES

Enclosed heads compartment with washbasin, electric toilet and shower with standing headroom

Hot and cold running water to the galley and the heads

Low maintenance GRP hull and deck

Spacious saloon and cockpit with waterproof upholstery

Teak decks, teak bathing platform and teak cockpit sole

Electric windlass, a 20kg galvanised anchor and 100ft of chain

One manual and two automatic electric bilge pumps

A touchscreen Raymarine display with speed, depth, GPS chart plotter and control of all

Galley includes two-burner cooker with fridge and stainless steel sink

Walk-through gate to the bathing platform with swimming ladder

All stainless steel fittings including flagpole, cleats, bollard, fender eyes, fairleads, safety rails, handrails, bow fitting with double roller, twin horn
